Description
The key feature of 3D Puff HTV (Heat Transfer Vinyl) garment vinyl is its ability to create a raised, three-dimensional effect on garments or fabrics. This vinyl has a foam-like texture that allows it to expand when heat is applied, creating a 3D effect that makes designs stand out. 3D Puff HTV is a popular choice for adding a unique and eye-catching look to logos, numbers, and other designs on t-shirts, hats, bags, and other garments. Additionally, it is available in a variety of colours and finishes, making it a versatile option for customizing a wide range of products.
Specification:
Thickness: 160 microns/0.16 mm
Carrier sheet: 100microns/0.1mm
Heat press setting:
- Preheat the heat press to 280°F-300°F (140°C-150°C).
- Place your fabric onto the heat press and preheat it for 5-10 seconds to remove any moisture and wrinkles.
- Place your design onto the fabric, with the carrier sheet facing up.
- Apply heat and pressure for 15-20 seconds using medium to high pressure.
- Peel off the carrier sheet while it is still warm.
- If the vinyl is not fully Puffed, repeat steps 4-5 until it is.
Iron-On setting:
- For using a household iron, set it to the Cotton/Linen or Wool setting, which is usually the highest temperature setting available.
- Turn OFF the steam setting on the iron.
- Preheat the area of the fabric where you want to apply the vinyl for 10-15 seconds.
- Place the weeded image onto the preheated fabric, liner side up. Apply high pressure (very important) with the iron for 25-30 seconds, pressing down firmly and evenly with both hands.
- Flip the fabric over and apply high pressure with the iron to the back of the material for an additional 25-30 seconds.
- Gently peel off the carrier sheet while it is still warm.
- If the vinyl is not fully puffed, repeat steps 4-6 until it is.
Note: Always perform a test cut and test application on a small, inconspicuous area of your fabric before applying your design to your final project to ensure the best results.
Care Instructions:
- Wait for 24 hours before washing the garment after applying HTV vinyl.
- Turn the garment inside out and wash it in cold water using a gentle cycle.
- Do not use bleach or any harsh cleaning agents that may damage the vinyl.
- Do not tumble dry the garment. Hang or lay it flat to air dry.
- Do not dry clean.
- If necessary, iron the garment inside out using a low or medium heat setting, avoiding direct contact with the vinyl.
Following these care instructions will help to preserve the quality and longevity of your heat transfer vinyl project.
